Club Cab custom subwoofer box build w/ pics

Reply




Thread Tools Search this Thread
  #1
Old 07-14-2014, 04:28 PM
Matt/E's Avatar
Matt/E Matt/E is offline
Registered User

Join Date: Jun 2014
Posts: 3
Default Club Cab custom subwoofer box build w/ pics

When I bought my 2001 Ram 2500 a couple years ago it came with the MTX Thunderform dual 10" powered sub under the rear seat...it had a buit in 200 watt amp and added some decent thump but nothing really spectacular and it would just turn into distortion if it was turned up too loud. I recently sold the Thunderform for $300 and bought an Obcon vented pre fab enclosure on Amazon and put 2 JL Audio 10W0v.2 4 ohm subs(300 rms each) in it powered by a JL XD600.1 amp(600 rms @ 2 ohms) and it was a huge improvement over the 200 watt MTX sealed unit but still didn't hit as hard and low as I wanted. Thoroughly disappointed with all of the other pre fab small sealed down firing enclosure options out there, I began designing my own custom MDF/ Fiberglass ported enclosure approx 2.25 ft3 tuned to 35Hz for a pair of Sundown SA-10s that will be powered by a Hifonics Brutus 1600.1 amp.

Here are some pics of my progress so far:

MTX Thunderform dual 10" 200 watts rms...goodbye!
Click the image to open in full size.

Obcon w/ JL 10's 600 watts rms(for sale)
Click the image to open in full size.

New box build

I had to cut out the carpet from the under side of the seat to gain an additional 2" of clearance for the subs and amp. The seat will go down all the way and lock. I probably won't be re using the seat release handles as I didn't make cut outs in the box to accommodate them.
Click the image to open in full size.

I cut out some carpet for increased mounting depth
Click the image to open in full size.

Click the image to open in full size.

Click the image to open in full size.
1/2" spacer rings were needed to make room for the massive magnets on the Sundown subs.
Click the image to open in full size.

Test fitting
Click the image to open in full size.

It sticks out less than an inch past the seat, slightly more on the corners
Click the image to open in full size.

Feel free to comment or ask questions.

http://www.sundownaudio.com/index.ph...sa-series.html


Click the image to open in full size.

Click the image to open in full size.
This ad is not displayed to registered and logged-in members.
Register your free account today and become a member on Dodge Forums!
Attached Images
File Type: jpg x236DRXP2CN-F.jpg (10.4 KB, 0 views)
File Type: jpg photo 1(3).jpg (95.2 KB, 0 views)
File Type: jpg photo12.jpg (70.4 KB, 57 views)
File Type: jpg photo27.jpg (63.6 KB, 59 views)
File Type: jpg photo34.jpg (89.8 KB, 58 views)
File Type: jpg photo41.jpg (65.0 KB, 55 views)
File Type: jpg photo51.jpg (65.2 KB, 56 views)
File Type: jpg photo14.jpg (86.0 KB, 58 views)

Last edited by Matt/E; 07-14-2014 at 04:45 PM..
Reply With Quote
  #2
Old 07-14-2014, 07:50 PM
Z.rawk95's Avatar
Z.rawk95 Z.rawk95 is offline
Professional

Join Date: May 2011
Vehicle: 2001 Dodge Ram 1500 2wd
Location: Mayo, FL
Posts: 165
Default

Looks good. I've been toying with the idea of making a box myself, but never mustered up the motivation. Although, if you posted dimensions, it might just give me enough inspiration to give it a shot... What are your plans to cover it with?
__________________
2001 Ram 1500 5.9 2wd. A few mods here and there.
Reply With Quote
  #3
Old 07-15-2014, 12:26 AM
Matt/E's Avatar
Matt/E Matt/E is offline
Registered User

Join Date: Jun 2014
Posts: 3
Default

I will post the dimensions after it's finished and in the truck and I know it fits and sounds the way I want it to...it's been a lot of work so far and my first time fiberglassing.
Reply With Quote
  #4
Old 07-15-2014, 03:18 AM
Derick C. Derick C. is offline
Professional

Join Date: Apr 2011
Vehicle: 92 gmc SB 2wd
Location: Auburn WA
Posts: 193
Default

I want to build one that does not stick out from under the seat.
__________________
97 RAM 1500 4x4 sold..old faithful 92GMC and new 1990 burb
Reply With Quote
  #5
Old 07-15-2014, 07:55 AM
Z.rawk95's Avatar
Z.rawk95 Z.rawk95 is offline
Professional

Join Date: May 2011
Vehicle: 2001 Dodge Ram 1500 2wd
Location: Mayo, FL
Posts: 165
Default

Actually, I might be interested in your old box and the JLs. I'll PM you later about it
Reply With Quote
  #6
Old 07-17-2014, 12:17 AM
Matt/E's Avatar
Matt/E Matt/E is offline
Registered User

Join Date: Jun 2014
Posts: 3
Default

Just got it sprayed with Rhino Lining, it's ready to go in!

Click the image to open in full size.

Click the image to open in full size.
Reply With Quote
  #7
Old 07-17-2014, 01:06 PM
ChillyPhil's Avatar
ChillyPhil ChillyPhil is offline
All Star

Join Date: Sep 2011
Vehicle: 1997 Dodge Ram 1500
Location: Pennsylvania
Posts: 918
showoff14
Send a message via Skype™ to ChillyPhil
Default

Looks awesome! I have a custom box I bought for 100 bucks from some website. It's been awhile...


The subs are facing the floor so I don't have to worry with anyone kicking them but it does suppress them a little bit. It also sticks out maybe an inch too.


I bought 2 10" Boss subs off amazon for 30 a piece and they do pretty awesome I must say.
__________________

1997 Dodge Ram 1500 5.2 ECSB 4x4: SCT Tuned, 180* Tstat, RC 5" Suspension Lift, RC Dual Stabilizers, Knockoff Flowmaster Muffler, Ebay Headers, High Flow Cat, HS 1.7 Roller Rockers, Cloyes Timing Set, Plenum Fix, Spectre 14x3
Reply With Quote
  #8
Old 07-18-2014, 07:33 AM
Z.rawk95's Avatar
Z.rawk95 Z.rawk95 is offline
Professional

Join Date: May 2011
Vehicle: 2001 Dodge Ram 1500 2wd
Location: Mayo, FL
Posts: 165
Default

Great job man. That really looks awesome. Hope you enjoy it
Reply With Quote
