Help!! 2500 hub removal!!

Thread Tools Search this Thread
Old 02-10-2009, 09:49 PM
ptown519 ptown519 is offline
Registered User
Join Date: Jan 2009
Posts: 8
Default Help!! 2500 hub removal!!

So I tried to tackle the right side ball joints on my 02' 2500 4x4. I have got it down to the hub. Axle is loose and the 4 bolts behind the hub removed. I have used a air chisel and large hammer all with pb blaster and it won't budge. any ideas??!!
Reply With Quote
Old 02-10-2009, 09:59 PM
95MaroonMonster's Avatar
95MaroonMonster 95MaroonMonster is offline
Record Breaker
Join Date: Jan 2009
Vehicle: 1995 Ram 1500
Location: Indiana
Posts: 2,087

eh, i used a hammer and chisel to remove the ones from my 95 half ton, and they were a real bitch to remove
i went in a pattern similar to tightning my lug nuts, it seemed to help
and a word of advice, on the hub bearing assembly, and knuckle, clean up the surfaces where they slip together, and put in some anitsiese
Reply With Quote
Old 02-10-2009, 10:31 PM
defiantmopar defiantmopar is offline
Join Date: May 2007
Posts: 63

I had the same problem when trying to remove mine. I was able to barrow the removal tool that is normally require to take off the hub bearing assemble which was still a PITA. I bent the plate and accually seperated the bearing assemble. Was A long day. But anyway somewhere I read about using a block of wood and wedging it between the assemble and the knuckle. Then just turning your steering wheel. Just can't remember where I seen that at. Never tried it myself but good luck. May just need a whole lot more of the PB blaster.
2000 Dodge Ram 2500 4x4 Sport:brushguard, 12000 warn winch , intake mod, round air filter, replaced steering components, bullballs a swinging
1965 Dodge Coronet 440 Hardtop: work in progress
Reply With Quote
Old 02-10-2009, 10:53 PM
olyelr's Avatar
olyelr olyelr is offline
Record Breaker
Join Date: Dec 2008
Vehicle: 2006 Dodge 2500, 4x4, Hemi, quad cab, short box, auto
Location: Elk Rapids, MI
Posts: 2,032

Try threading the 4 back bolts back in most of the way (about a 1/4" from tight) and beat on them to loosen it. Just make sure you beat on a socket instead of the bolt head. Thats how I got them off my half ton.
<img src= border=0 alt= class=post_inline_image />
2006 Ram, 4x4, 2500, Big Horn, Hemi, quad cab, short box
Other than the leveling kit and 285's, she's a virgin.
Reply With Quote
Old 02-10-2009, 11:19 PM
RM_Indy RM_Indy is offline
Record Breaker
Join Date: Nov 2005
Vehicle: 11 1500 Bighorn QC 4x4 & what started out as 96 Indy :)
Location: Ontario Canada
Posts: 1,827

Large hammer probably wont cut it!
Took my 2500 to the stealer to get them to install ebc dimpled rotors/pads, shoes as well as one rear cyl. & axle seal, front bearings. Trucks been outside its whole life and I hate working on it in the driveway in winter (shes a bit rusty underneath)
25yr mech (older than me) soaked it and beat on the hubs & drums for over 3hrs with a sledgehammer. Beat the living **** out of them trying to get them to break free. Felt sorry for him till I got the bill lol.
11 1500 Bighorn Hemi 4x4
96 Ram/Indy Procharged 408 (s/c 360 times in sig)
Tons of pics, tips, mod list, timeslips & vids @
Reply With Quote
Old 02-10-2009, 11:19 PM
helms helms is offline
All Star
Join Date: Jun 2007
Vehicle: 2002 2500 SLT laramie 5.9
Location: Langley, BC, Canada
Posts: 981

there is a power steering trick, i dont know the specifics but im sure you can figure it out if you look at it. I helped a mechanic at the dealer do this. if you turn the truck on so you have PS, you can take a socket (not sure what size) and place it in between the hub and housing, then get a friend to turn the wheels to trap the socket and crank really hard while you beat the **** you of the knuckle. you will have to alternate between the front and back of the hub a few times, but it works, i know it does
2002 2500, 5.9 V8, 4x4, MSD, Flowmaster super 40 cat delete, Airaid, Autometer, BDS, Rancho, 35" Toyos
Reply With Quote
Old 02-10-2009, 11:48 PM
Kraiger's Avatar
Kraiger Kraiger is offline
Join Date: Feb 2009
Vehicle: 2001 Dodge Ram 1500 4x4 Sport Off-Road..ish.
Location: OHIO
Posts: 402

How i did mine was with the 4 bolts in and beat it will a hammer..can try a little heat on the bearing to..but yes they are fun...thats one reason im doing manual hub conversion..pricey yes..but no more hub failures....MAKE SURE when you put the new one in that you put anti-seeze around the part that goes into the knuckle..that helps alot.. as far as a tool goes i have seen a dealer here in to make a slide hammer and uses a rotor that you bolt onto the hub then use the slide hammer to pull it off..
Reply With Quote
