Trying to install a new horn..... don't know what I'm doing.....

Reply




Thread Tools Search this Thread
  #1
Old 03-24-2009, 10:36 PM
Silver Kracker's Avatar
Silver Kracker Silver Kracker is offline
Registered User
Garage is empty, add now

Join Date: Dec 2008
Vehicle: Dodge Ram 1500
Location: Dallas, Texas
Posts: 22
Default Trying to install a new horn..... don't know what I'm doing.....

I recently bought the 'big boss' horn from FIAMM, and am trying to figure out how to install it. My main problem first off is I can't find my original horn and its compressor, and does anyone have any ideas where to install the trumpets?

Click the image to open in full size.

I've looked all over the internet and theres not a good tutorial out there to help me, I'd like to get this thing up as soon as possible because admit it......... the stock horns suck
This ad is not displayed to registered and logged-in members.
Register your free account today and become a member on Dodge Forums!
__________________

2001 Dodge Ram 1500 SLT, 5.9L V8. 35x12.5xR17, 3" Body Kit
Reply With Quote
  #2
Old 03-24-2009, 11:15 PM
95MaroonMonster's Avatar
95MaroonMonster 95MaroonMonster is offline
Record Breaker
Garage is empty, add now

Join Date: Jan 2009
Vehicle: 1995 Ram 1500
Location: Indiana
Posts: 2,087
Default

stock horn first off don't have a compressor, and the horns are located right behind the bumper on the left side of the truck, i replaced mine a while back when it died
__________________
'95 RAM 1500 318, AUTO, 14X3, HUGHES PLENUM FIX, NO CAT, GLASSPACK, 2" LIFT, OVERLOADS, CB, DUAL WHIPS, HERCULINED ROCKERS, MORE TO COME
Reply With Quote
  #3
Old 03-24-2009, 11:25 PM
Laramie1997's Avatar
Laramie1997 Laramie1997 is offline
Grand Champion
1997 Dodge Ram 1500
My Garage

Join Date: Sep 2008
Vehicle: 2013 Charger R/T Road & Track
Location: Springfield MO
Posts: 6,998
garton1940
Default

There is no compressor on the stock horns for these trucks. They are a dual note which means that there is two electric motorized horns to remove. these are located on the front left bumper brace. At least thats where they are on mine. I mounted my horns in mine on the same brace. The wiring can be a little confusing to get done though..
__________________
Call it an early midlife crisis.
Reply With Quote
  #4
Old 03-24-2009, 11:45 PM
Jase's Avatar
Jase Jase is offline
Rookie
Garage is empty, add now

Join Date: Mar 2009
Vehicle: 2001 Ram 1500 5.9 V8
Location: Montana
Posts: 68
Default

It's really pretty simple when you wrap your mind around it. I basically spliced mine into the stock horn by wiring it into the trigger wire (the green one).
Click the image to open in full size.
Also, be sure to get a fuse in there on the wire from your battery. Other than that, follow the directions about the relay. all you really need are wire, butt connectors, and female terminals.

As for placement... not sure if this was good or bad idea, but it was sure as hell easy. haha
Click the image to open in full size.

Last edited by Jase; 03-24-2009 at 11:59 PM..
Reply With Quote
  #5
Old 03-25-2009, 02:30 AM
TIMIDONE's Avatar
TIMIDONE TIMIDONE is offline
All Star
Garage is empty, add now

Join Date: Mar 2008
Vehicle: 1998 Dodge Ram 1500 4x4 5.9L 14x3 K&N Intake and Super 44 Flowmaster
Posts: 880
Default

no compressor...I hated that as I wanted to install train horns! but the horns (on my rig) are on the passenger side front...plenty of room...thought I'd install an extra battery there.

BTW....anyone got suggestions for a good LOUD horn that doesn't require a compressor? I don't want to go through all that work...just want to wire it up.
__________________
TIMIDONE - 1998 Dodge Ram 1500 V8 5.9L 4WD: Mr.Gasket 14" Air Cleaner w/ K&N 14"x3" #1650 filter w/ Super44 Flowmaster Exhaust, BFGoodrich All Terrain T/A KO

/\ My New Toy! /\
Reply With Quote
  #6
Old 03-25-2009, 02:56 AM
Laramie1997's Avatar
Laramie1997 Laramie1997 is offline
Grand Champion
1997 Dodge Ram 1500
My Garage

Join Date: Sep 2008
Vehicle: 2013 Charger R/T Road & Track
Location: Springfield MO
Posts: 6,998
garton1940
Default

www.jcwhitney,com
They have a large amount of horns both air powered and electric.
__________________
Call it an early midlife crisis.
Reply With Quote
  #7
Old 03-25-2009, 07:38 PM
BlueBeast2's Avatar
BlueBeast2 BlueBeast2 is offline
Champion
1996 Ford Mustang
My Garage

Join Date: Jul 2005
Vehicle: 01 Ram 2500, 96 Mustang GT, 94 Mustang GT
Location: Parkesburg, PA
Posts: 2,945
Send a message via AIM to BlueBeast2 Send a message via Yahoo to BlueBeast2
Default

Quote:
Originally Posted by TIMIDONE View Post
no compressor...I hated that as I wanted to install train horns! but the horns (on my rig) are on the passenger side front...plenty of room...thought I'd install an extra battery there.

BTW....anyone got suggestions for a good LOUD horn that doesn't require a compressor? I don't want to go through all that work...just want to wire it up.
you sissy lol. I doubt it will be that hard to install a compressor and tank. I'll let ya know some day if I ever get around to it on mine.
