4wd not engaging

Reply




Thread Tools Search this Thread
  #1
Old 04-03-2010, 03:45 PM
willstruck's Avatar
willstruck willstruck is offline
Professional
Garage is empty, add now

Join Date: Jan 2009
Vehicle: 97 Diesel 2500, manual trans.
Location: Temecula, CA
Posts: 246
Default 4wd not engaging

I've been trying to figure out what's wrong with my truck, I followed this:
http://www.dodgeram.org/tech/repair/..._engagment.htm

  1. Shift into 4WD and move truck a couple of feet
  2. If light is still off, park truck, block the wheels, set the park brake, jack right front wheel, and try to hand spin the wheel
    • If wheel doesn't turn, 4x4 is functioning properly but there is a wiring problem: use an ohmmeter to check the 4x4 switch, wiring, fuse, and bulb.
    • If wheel turns freely, the front axle or transfer case is not engaged: continue...
  3. Attempt to hand spin the front driveshaft If the driveshaft WILL spin, the transfer case is not engaged Check the transfer case shift linkage, problem is in linkage (or in the tran$fer ca$e internal$ <-- yes this means $$, ouch!)
    • If the driveshaft will NOT spin, the transfer case is engaged properly: continue...
  4. USE CAUTION! With transmission in neutral or park, start engine, measure vacuum on the two vac lines at front axle shift motor. One line should have approx 20" vacuum, other line should have none.
    • If NO vacuum measured, look for vacuum leak or bad vacuum switch.
    • If both lines have vacuum, look for a bad vacuum switch or ruptured CAD actuator diaphragm.
    • If one line has 20" +/- vacuum:
      • Move transfer case lever to 2WD, measure vacuum again. Lines should have swapped vacuum signals.
        • If No: vacuum switch bad or 4WD shift linkage needs adjusting
        • If Yes: Vacuum motor bad or stuck, or shift fork stuck: continue
  5. Remove vacuum shift motor from the axle, attach vac lines to shift motor, engage/disengage 4WD. Does shift motor plunger move at least 1/2"?
    • No: shift motor bad
    • Yes: Check axle shift fork and vacuum motor for binding
Did it all. Driveshaft was locked, but wheel turned. Checked the lines, got vacuum from one. Put it into 4, got vacuum from the other. Pulled the assembly off the axle, had someone switch between 2 and 4, and the fork moved back and forth. Put it back together, still no 4wd.
This ad is not displayed to registered and logged-in members.
Register your free account today and become a member on Dodge Forums!
__________________
1997 Diesel 4x4, manual transmission, 168,000 miles. Boost gauge, Dodge plastic bedliner, factory chrome brush guard. Fuel plate, AFC, and star wheel adjusted. 16" Rockcrusher rims, 33" Maxxis Bighorns.
Reply With Quote
  #2
Old 04-03-2010, 04:05 PM
j_mccans's Avatar
j_mccans j_mccans is offline
Registered User
Garage is empty, add now

Join Date: Mar 2010
Vehicle: 1996 dodge 1500 4x4 reg cab short box
Location: Northern Michigan
Posts: 20
Default

do you have a broken axleshaft?
Reply With Quote
  #3
Old 04-03-2010, 05:41 PM
hammerhead1985 hammerhead1985 is offline
Registered User
Garage is empty, add now

Join Date: Feb 2010
Vehicle: 2001 dodge ram 1500
Location: fort eustis
Posts: 45
Default

does the four wheel drive indicator light on your dash come on when you put it in four wheel drive. When the vacuum diaphram slides the collar over to lock the shafts together it pushes in the switch that activates the 4X4 light. If it's not coming on, the collar and plunger aren't moving correctly.
Reply With Quote
  #4
Old 04-04-2010, 01:29 PM
willstruck's Avatar
willstruck willstruck is offline
Professional
Garage is empty, add now

Join Date: Jan 2009
Vehicle: 97 Diesel 2500, manual trans.
Location: Temecula, CA
Posts: 246
Default

Quote:
Originally Posted by j_mccans View Post
do you have a broken axleshaft?
Not that I know of... how would I tell?
__________________
1997 Diesel 4x4, manual transmission, 168,000 miles. Boost gauge, Dodge plastic bedliner, factory chrome brush guard. Fuel plate, AFC, and star wheel adjusted. 16" Rockcrusher rims, 33" Maxxis Bighorns.
Reply With Quote
  #5
Old 04-04-2010, 01:33 PM
willstruck's Avatar
willstruck willstruck is offline
Professional
Garage is empty, add now

Join Date: Jan 2009
Vehicle: 97 Diesel 2500, manual trans.
Location: Temecula, CA
Posts: 246
Default

Quote:
Originally Posted by hammerhead1985 View Post
does the four wheel drive indicator light on your dash come on when you put it in four wheel drive. When the vacuum diaphram slides the collar over to lock the shafts together it pushes in the switch that activates the 4X4 light. If it's not coming on, the collar and plunger aren't moving correctly.
Good point. I was getting vacuum, but I don't have a vacuum gauge so I don't know how much I was actually getting. If the vacuum control isn't pulling enough pressure to move it, that could be my problem.

FYI, my 4x4 light never has come on, but 4low always has. Bulb burnt out?

I was planning on replacing the vacuum system with the cable actuator, but I just haven't got around to it yet.
__________________
1997 Diesel 4x4, manual transmission, 168,000 miles. Boost gauge, Dodge plastic bedliner, factory chrome brush guard. Fuel plate, AFC, and star wheel adjusted. 16" Rockcrusher rims, 33" Maxxis Bighorns.
Reply With Quote
  #6
Old 04-04-2010, 04:37 PM
green97's Avatar
green97 green97 is offline
Rookie
1997 Dodge Ram 1500

Join Date: Mar 2010
Vehicle: 1997 dodge ram 1500
Location: canton ohio
Posts: 52
Default

Check you shifter linkage it's a small rod coming from the transfer case there is just a small bolt locking it in you can adjust that

I used to put my truck in 4x4 and it would go a few feet then go to neutral when I adjusted the linkage all was well again
Reply With Quote
  #7
Old 04-04-2010, 05:49 PM
dhvaughan's Avatar
dhvaughan dhvaughan is offline
Hall Of Fame
Garage is empty, add now

Join Date: Jul 2006
Vehicle: 01 1500 4wd
Location: Gainesville, Ga.
Posts: 12,192
Default

good work so far, but can you put the truck up on 4 jack stands and start at the t-case and work down stream. check things in this order.
does front drive shaft turn.
do front wheels turn (probably not since you wrote this post)
does vacuum switch from one line at the cad to the other.
remove cad.
does the fork slide over.
can you move the coupler byhand on/off the 2 axle pieces.
(there's a bushing in there that might be worn out causing out of alignment. also coupler or shaft could be buggered up).
can you get the light on the dash to work (its activated by switch on cad, only when everything slides all the way over).
__________________
01 1500 Reg Cab 4wd 5.2 auto 3.55 285/75/16 steps tow hooks sc3815 180 3923 trans cooler filter posilok powertrax (removed) timbren britebox pioneer head rockford amp speaker cobra cb firestick hughes plenum water pump timing chain oil pump rear main hub bearings brakes shocks cracked dash cad bushings seals ujoints trackbar tcase Robert Griffin Trans

Last edited by dhvaughan; 04-04-2010 at 06:24 PM..
Reply With Quote
  #8
Old 04-04-2010, 07:00 PM
95RAM360's Avatar
95RAM360 95RAM360 is offline
Grand Champion
1995 Dodge Ram 1500

Join Date: Aug 2009
Vehicle: 95 Dodge Ram 1500 5.9 SLT Laramie 4x4
Location: MAINE
Posts: 5,581
Send a message via Yahoo to 95RAM360
Default

possibly a Posi-Lok is in order?
__________________
1995 Dodge Ram 1500 SLT Laramie 4x4, US Wheels, Courser AT2 tires, Audio System, Rebuilt Transmission, 4.10 gears, Hughes Plenum, Kegger Mod, 8.5mm Spark wires, Bed Rails, Side Steps, Truck box, New Timing Chain, Hollow CAT, Cherry Bomb Turbo Muffler, New Harmonic Balancer, New Transfer Case
Reply With Quote
  #9
Old 04-06-2010, 09:49 PM
willstruck's Avatar
willstruck willstruck is offline
Professional
Garage is empty, add now

Join Date: Jan 2009
Vehicle: 97 Diesel 2500, manual trans.
Location: Temecula, CA
Posts: 246
Default

Quote:
Originally Posted by dhvaughan View Post
good work so far, but can you put the truck up on 4 jack stands and start at the t-case and work down stream. check things in this order.
does front drive shaft turn.
do front wheels turn (probably not since you wrote this post)
does vacuum switch from one line at the cad to the other.
remove cad.
does the fork slide over.
can you move the coupler byhand on/off the 2 axle pieces.
(there's a bushing in there that might be worn out causing out of alignment. also coupler or shaft could be buggered up).
can you get the light on the dash to work (its activated by switch on cad, only when everything slides all the way over).
front drive shaft locks to t-case when in 4
wheels don't turn
vacuum switches over, but not sure how much vacuum, no gauge
fork slides over
have not tried to move coupler by hand. thanks, i'll try that
light has never worked, except 4lo. didn't think to check it when moving fork by hand.
__________________
1997 Diesel 4x4, manual transmission, 168,000 miles. Boost gauge, Dodge plastic bedliner, factory chrome brush guard. Fuel plate, AFC, and star wheel adjusted. 16" Rockcrusher rims, 33" Maxxis Bighorns.
Reply With Quote
  #10
Old 04-06-2010, 09:51 PM
willstruck's Avatar
willstruck willstruck is offline
Professional
Garage is empty, add now

Join Date: Jan 2009
Vehicle: 97 Diesel 2500, manual trans.
Location: Temecula, CA
Posts: 246
Default

Quote:
Originally Posted by 95RAM360 View Post
possibly a Posi-Lok is in order?
Ya,but I wanted to make sure that the problem was isolated to the CAD system first.

It's $202 from the company, anyone know of a cheaper place?
__________________
1997 Diesel 4x4, manual transmission, 168,000 miles. Boost gauge, Dodge plastic bedliner, factory chrome brush guard. Fuel plate, AFC, and star wheel adjusted. 16" Rockcrusher rims, 33" Maxxis Bighorns.
Reply With Quote
