Power Outlets Not Working

Reply




Thread Tools Search this Thread
  #1
Old 07-19-2007, 08:43 PM
Pirata's Avatar
Pirata Pirata is offline
Champion
Garage is empty, add now

Join Date: Apr 2007
Vehicle: 2008 Smart ForTwo
Location: Communistwealth of Virginia
Posts: 4,022
Default Power Outlets Not Working

I was on the second day of my trip andI blew both of the front power outlets in my truck. I pulled over to a rest stop and none of the fuses were blown unless there's another fuse box that the one in the manual. Anyone have this happen to them before? I have an appointment at the dealership in a week so I can get it checked then but if anyone has a simple solution so I don't have to waste an hour at the dealership please let me know.
This ad is not displayed to registered and logged-in members.
Register your free account today and become a member on Dodge Forums!
__________________
Army Retired

Pushing the limits means getting out of my comfort zone and giving more when I don't think I have any left.
Reply With Quote
  #2
Old 07-20-2007, 11:05 AM
Pirata's Avatar
Pirata Pirata is offline
Champion
Garage is empty, add now

Join Date: Apr 2007
Vehicle: 2008 Smart ForTwo
Location: Communistwealth of Virginia
Posts: 4,022
Default RE: Power Outlets Not Working

No one?
__________________
Army Retired

Pushing the limits means getting out of my comfort zone and giving more when I don't think I have any left.
Reply With Quote
  #3
Old 07-21-2007, 12:40 AM
FFMedic1479's Avatar
FFMedic1479 FFMedic1479 is offline
All Star
Garage is empty, add now

Join Date: Jan 2007
Location: Connecticut
Posts: 982
Default RE: Power Outlets Not Working

Not a clue, sorry... must be a relay or something jammed up... let us know how you make out... good luck.
__________________
Career Firefighter L2704
2005 5.7L Ram 2500 Quad Cab 4x4 HD, K&N CAI, Gibson SuperTruck Exhaust, Superchips Flashpaq, Kenwood KVT-512, JL 3 Channels in the doors, JL 4 Channel Amp, RF Mono Amp, JL W1 10", Leveling Kit, Dynapro 35x1250x17, NFab Steps; 91 Wrangler Project Jeep
Reply With Quote
  #4
Old 07-21-2007, 08:39 AM
Pirata's Avatar
Pirata Pirata is offline
Champion
Garage is empty, add now

Join Date: Apr 2007
Vehicle: 2008 Smart ForTwo
Location: Communistwealth of Virginia
Posts: 4,022
Default RE: Power Outlets Not Working

I was trying to avoid going to the dealership but I guess I'll have to so I cen get this checked out.
__________________
Army Retired

Pushing the limits means getting out of my comfort zone and giving more when I don't think I have any left.
Reply With Quote
  #5
Old 07-21-2007, 10:53 AM
chadmech28 chadmech28 is offline
Professional
Garage is empty, add now

Join Date: Mar 2007
Location:
Posts: 144
Default RE: Power Outlets Not Working

What year is your truck and what motor? It sounds like you may have a problem with your IPM.
__________________
2009 Ram 1500 4x4 sport
2009 polaris sportsman 500ho
1972 plymouth duster 340
2004 mxz x 800ho
Reply With Quote
  #6
Old 07-21-2007, 03:55 PM
Pirata's Avatar
Pirata Pirata is offline
Champion
Garage is empty, add now

Join Date: Apr 2007
Vehicle: 2008 Smart ForTwo
Location: Communistwealth of Virginia
Posts: 4,022
Default RE: Power Outlets Not Working

20071500. All 3 power outlets were working while I was on my trip until about the 1000 mile mark and 2 of them went within 10 minutes or so. I had thought it was a fuse but none of the fuses were bad when I checked at the next gas station.
__________________
Army Retired

Pushing the limits means getting out of my comfort zone and giving more when I don't think I have any left.
Reply With Quote
  #7
Old 07-21-2007, 09:01 PM
chadmech28 chadmech28 is offline
Professional
Garage is empty, add now

Join Date: Mar 2007
Location:
Posts: 144
Default RE: Power Outlets Not Working

They are all on different fuses fuse 1, 30 and 40 the tpim controls all 3 but they don't all share the same curcuit. The lighter and power outlet both share the same ground G203 check this. The way chrysler has been going with the quality control lately, I wouldn't be suprised if it was loose. hope this helps
__________________
2009 Ram 1500 4x4 sport
2009 polaris sportsman 500ho
1972 plymouth duster 340
2004 mxz x 800ho
Reply With Quote
  #8
Old 07-22-2007, 09:40 AM
Pirata's Avatar
Pirata Pirata is offline
Champion
Garage is empty, add now

Join Date: Apr 2007
Vehicle: 2008 Smart ForTwo
Location: Communistwealth of Virginia
Posts: 4,022
Default RE: Power Outlets Not Working

Where is G203 located in the vehicle?
__________________
Army Retired

Pushing the limits means getting out of my comfort zone and giving more when I don't think I have any left.
Reply With Quote
  #9
Old 07-27-2007, 08:10 AM
Pirata's Avatar
Pirata Pirata is offline
Champion
Garage is empty, add now

Join Date: Apr 2007
Vehicle: 2008 Smart ForTwo
Location: Communistwealth of Virginia
Posts: 4,022
Default RE: Power Outlets Not Working

Actually the fuses on a 2007 are a 1, 38 & 40. I looked in the manual and it only listed #1 so that's the one I checked. I finally out of desparation of not wanting to go to the dealer I checked the every other fuse in the fuse box and I found 38 and 40 were out. I replaced them and they worked like a dandy.
__________________
Army Retired

Pushing the limits means getting out of my comfort zone and giving more when I don't think I have any left.
Reply With Quote
  #10
Old 07-27-2007, 10:42 AM
Pappy_FB Pappy_FB is offline
Record Breaker
Garage is empty, add now

Join Date: Apr 2007
Location: Florida
Posts: 1,283
Default RE: Power Outlets Not Working

Glad you gotit fixed.
