Dodge Ram 1994-2001: How to Replace Cruise Control Switch

The cruise control function in your Dodge Ram is a life saver during those long drives. If yours has stopped working, continue reading for this DIY on how to replace the cruise control switch, and get you rolling smoothly down the highway once again.

By Brett Foote - July 15, 2015
Contributors: Gary-L

This article applies to the Dodge Ram 2nd Generation (1994-2001).

One common problem area among 2nd generation Dodge Rams lies within the cruise control switch. If your truck's cruise control switch has become difficult to operate or has ceased to work altogether, you should consider replacing it. First, however, you will want to check for possible vacuum leaks in case the switch isn't what's causing your non-cruising stress. Check the vacuum hose located underneath the batter to the cruise control solenoid, and inspect if it is cracked, damaged, or leaking. It will only cost you $5 to buy and attach a new hose. If you don't have any problems with vacuum, this article will guide you through the easy process of changing out the cruise control switch in your Dodge Ram.

Materials Needed

  • Phillips screwdriver
  • Torx screwdriver (optional depending on model)

Step 1 – Remove the cruise control switch

Remove the two Phillips head screws that secure the cruise control switch to the steering wheel. They are located on the back side of the switch. Then carefully disconnect the electrical connector by pulling outward on its two tabs, and simultaneously pulling it off of the switch. Pull the old cruise control switch out and set it aside.

Figure 1. Remove two screws holding the cruise control switch in place, and unplug the electrical connector.

Note

In some Dodge Ram models, the electrical connector is plugged in underneath the steering wheel horn cover. If this is the case with your Ram, you must also remove the switch panel on the right-hand side of the steering wheel, and then the two Torx bolts holding the cover in place. This bolt is visible in Figure 1.

Step 2 – Install the new cruise control switch

Plug in the electrical connector to the new cruise control switch. Set the new switch in place, and tighten the two Phillips mounting screws.

If you had to remove the steering wheel horn cover, re-install it as well as the two Torx bolts before the final installation. Test the switch to ensure that everything works as intended.

Figure 2. Install the new cruise control switch.
