2003 Ram OBD2 Port Fell Apart!

Thread Tools

Search this Thread

  #1
Old 03-13-2009, 08:12 PM
allisnut's Avatar
allisnut
allisnut is offline
Registered User
Thread Starter
Join Date: Mar 2009
Posts: 2
Likes: 0
Received 0 Likes on 0 Posts
Default 2003 Ram OBD2 Port Fell Apart!
I need a wiring diagram for the OBD2 port on my 2003 Ram w/ 4.7L v-8. My port came apart and the wire ends are out of place.

Thanks,

Adam

Reply Like
  #2
Old 03-13-2009, 08:43 PM
Parts/Service's Avatar
Parts/Service
Parts/Service is offline
Champion
Join Date: Mar 2004
Location: Bremen, GA.
Posts: 2,703
Likes: 0
Received 2 Likes on 2 Posts
Default
Cavity wire color function
1 empty
2 light blue/violet stripe pci bus
3 empty
4 black/dark green stripe ground
5 orange/black stripe ground
6 empty
7 pink sci transmit
8 empty
9 pink/light blue stripe sci receive
10 empty
11 empty
12 light green sci receive
13 empty
14 empty
15 white/dark green stripe sci transmit
16 pink fused b+

Reply Like
  #3
Old 03-13-2009, 09:35 PM
allisnut's Avatar
allisnut
allisnut is offline
Registered User
Thread Starter
Join Date: Mar 2009
Posts: 2
Likes: 0
Received 0 Likes on 0 Posts
Default Thanks!
Cool - thank you very much!

Adam

Reply Like
  #4
Old 03-24-2009, 10:47 AM
Texelfan68's Avatar
Texelfan68
Texelfan68 is offline
Registered User
Join Date: Mar 2009
Posts: 4
Likes: 0
Received 0 Likes on 0 Posts
Default
Hello,
I need a wiring diagram for the OBD2 port on my 2005 Ram w/ 5.7L v-8 Hemi.
Thanks

Reply Like
  #5
Old 03-03-2011, 10:54 AM
weedahoe's Avatar
weedahoe
weedahoe is offline
Hall Of Fame
Hall of Fame Member
Join Date: Mar 2009
Location: South GA
Posts: 19,166
Received 19 Likes on 18 Posts
Default
Originally Posted by Texelfan68
Hello,
I need a wiring diagram for the OBD2 port on my 2005 Ram w/ 5.7L v-8 Hemi.
Thanks
Welcome to the site. You can click on the links in my signature to download the service manual for your truck and find those diagrams in there

Reply Like
The following users liked this post:
bosljeff (05-26-2021)
  #6
Old 04-07-2013, 06:55 PM
Griffix's Avatar
Griffix
Griffix is offline
Registered User
Join Date: Apr 2013
Posts: 6
Likes: 0
Received 1 Like on 1 Post
Default
I have a 2003 Dodge Ram 1500 4x4 with the 4.7
My OBD port is smashed. How do I go about buying another one?????
Thanks!

Reply Like
The following users liked this post:
DBWhite (06-24-2023)
  #7
Old 05-26-2021, 10:43 PM
bosljeff's Avatar
bosljeff
bosljeff is offline
Registered User
Join Date: May 2021
Posts: 4
Received 1 Like on 1 Post
Default
Can’t find your link. Apologies. I am losing light and desperately just need guide to where these 8 colors go and into what hole in the housing.


2004 ram 1500 5.7


Originally Posted by weedahoe
Welcome to the site. You can click on the links in my signature to download the service manual for your truck and find those diagrams in there

Reply Like
The following users liked this post:
DBWhite (06-24-2023)

Trending Topics

  #8
Old 08-22-2021, 09:25 AM
Vertvic's Avatar
Vertvic
Vertvic is offline
New Member
Join Date: Aug 2021
Posts: 1
Likes: 0
Received 0 Likes on 0 Posts
Default
Hey man did you ever find how it went, having the same problem

Reply Like
  #9
Old 08-22-2021, 10:51 PM
Magnoom's Avatar
Magnoom
Magnoom is offline
Record Breaker
Join Date: Apr 2019
Posts: 1,474
Received 216 Likes on 196 Posts
Default


Reply Like
