Blinker woes, WTF could it be.

Thread Tools

Search this Thread

Old Dec 13, 2011 | 01:54 PM
  #1
jdsupera's Avatar
jdsupera
Thread Starter
|
Registered User
Joined: Jan 2011
Posts: 5
Likes: 0
Default Blinker woes, WTF could it be.

94 Dodge Ram 1500 5.2
Blinkers stopped working one day out of the blue and have not worked since. Flashers, however do work. I have checked all fuses and they were good, even reseated every one but didn't help. Next I replaced the flashers, my truck has two 2 prong flashers replaced both of them, nothing. Next I took the steering column shoud off and inspected for loose or damaged wiring, nothing. And finally while I had the shoud apart I replaced the multi function ignition switch....and you guessed it....Nothing. I'm at a loss at what the heck to throw at it next. Any help would greatly appreciated.

Reply
Old Dec 13, 2011 | 06:33 PM
  #2
zman17's Avatar
zman17
Retired Moderator - RIP
Joined: May 2008
Posts: 18,729
Likes: 17
From: NH
Default

You need a Haynes or download one of the free manuals from the FAQ/DIY section, so you can trace the wires. Specifically the grounds. Also check the harness/plug at the back if you have tow package . If all else fails, maybe this will help, http://kalecoauto.com/index.php?main...&products_id=6

Reply
Old Dec 13, 2011 | 10:24 PM
  #3
97ramrod1500's Avatar
97ramrod1500
Captain
Joined: Dec 2011
Posts: 555
Likes: 3
From: Wisconsin
Default

if you have a digital multimeter try back probing the bulbs to see if they're getting current (while the blinker is on of course). if you don't have a multimeter a test light would work also. if no current then trace the wire back to the power source. if power is there, follow the wire to the ground location. (for anything on the ground side of the bulb you will need a multimeter.) a test light won't work because ideally, the bulb should be dropping the 12 volts

Reply
Old Dec 14, 2011 | 10:31 AM
  #4
wermbang's Avatar
wermbang
Professional
Joined: Aug 2009
Posts: 226
Likes: 0
From: Des Moines
Default

Name:  BlinkFluid.jpg
Views: 29
Size:  28.5 KB

Reply
Old Dec 14, 2011 | 11:04 AM
  #5
UnregisteredUser's Avatar
UnregisteredUser
Grand Champion
Joined: Apr 2010
Posts: 5,011
Likes: 6
From: Meeker, CO
Default

Originally Posted by 97ramrod1500
(for anything on the ground side of the bulb you will need a multimeter.) a test light won't work because ideally, the bulb should be dropping the 12 volts
Just clip the lead of the test light to the B+ (battery positive) terminal to run down grounds. Nuthin' to it.

Reply
Old Dec 14, 2011 | 12:50 PM
  #6
Pacmanloads's Avatar
Pacmanloads
Captain
Joined: Oct 2009
Posts: 607
Likes: 0
From: Moncton , New Brunswick
Default

If you have wiring for trailer lights , start there , I have had issues with wire corrosion . You a test light .

Reply
