Front door speaker replacement, depth

Reply




Thread Tools Search this Thread
  #1
Old 05-26-2010, 03:49 PM
althorp althorp is offline
Registered User
Garage is empty, add now

Join Date: Dec 2006
Location:
Posts: 33
Default Front door speaker replacement, depth

I have a 2001 Ram 1500 with the factory stereo and four speakers. Only one of the four speakers is currently working. I took off the door panel on the drivers' side and disconnected the speaker wire harness and tested the stereo and wire leading to this location by attaching a new speaker at this point. And, where it had not worked before, sound came out of the new speaker. I concluded that the drivers' side speaker is dead. I couldn't see anything wrong with it.

In any case, I've decided to replace the front speakers, and have done some exploring at Crutchfield. Their recommended solution is to install 5-1/4" speakers with an adapter. Or, to install a 6x9 speaker made for Crutchfield by Sound Ordinance, which fits the Ram without modification (the ONLY speaker which fits without modification!!). Others have posted that Crutchfield offers tips on modifications, but I couldn't find them.

After looking at various threads on this site, I see that speaker depth limits the speakers that can be installed at this location. Some have apparently chosen to mount their speakers above the door panel. Is there a nice looking way to do this? I'd prefer to install 6x9 speakers both because of better sound, but I'd rather not do this and have to hack the interior of the vehicle.

Any tips?
This ad is not displayed to registered and logged-in members.
Register your free account today and become a member on Dodge Forums!
__________________
2001 Dodge Ram 1500, with 5.2 liter V8 engine, and 4WD. About 150,000 miles as of 12/30/06. Manual transmission, long bed.
Reply With Quote
  #2
Old 05-26-2010, 04:17 PM
bigtman07's Avatar
bigtman07 bigtman07 is offline
Captain
1998 Dodge Ram 1500

Join Date: Sep 2009
Vehicle: 1998 Dodge Ram 1500 Sport
Location: Eaton Ohio
Posts: 719
Send a message via Yahoo to bigtman07
Default

Well I personally used the spacer idea. I have 2 pioneer 6x9's in my doors. 220watts each. I went to Ace hardware and got a couple of 1/2 inch nuts. Just big enough to space the speaker out. then got longer screws like the mounting ones. My setup fits right behind the factory door panel with about a 1/4inch to spare. So you could use just about an 6x9 that you wanted. I got mine from craigslist. But where you get it from is up to you. there is a DIY in the FAQ section that will help you out.
__________________

Dodgeforum.com it's not an addiction it's a way of life! RTC#23 STC#17 Picture Game!
Reply With Quote
  #3
Old 05-26-2010, 05:30 PM
althorp althorp is offline
Registered User
Garage is empty, add now

Join Date: Dec 2006
Location:
Posts: 33
Default

Thanks for that suggestion! I will check out the DIY tip.
__________________
2001 Dodge Ram 1500, with 5.2 liter V8 engine, and 4WD. About 150,000 miles as of 12/30/06. Manual transmission, long bed.
Reply With Quote
  #4
Old 05-26-2010, 05:34 PM
revvinram revvinram is offline
Professional
Garage is empty, add now

Join Date: Jan 2009
Vehicle: 99 Dodge Ram 1500 5.2
Location: Delaware
Posts: 134
Default

Had the same issue with my 99, I ordered Alpine SP2's (I think) from crutchfield and used the spacer that came with them meant to be used when putting them in the back dash, to extend them out from the door panel basically same thing Bigtman did.. A year ago when I did mine all they recommended were 5-1/4". The Alpine's were the most shallow.
I have heard alot of people say some Pioneer's work also.. I decided to do Alpine's front & rear along with a JVC head unit... No Regrets..
Reply With Quote
  #5
Old 05-26-2010, 05:38 PM
althorp althorp is offline
Registered User
Garage is empty, add now

Join Date: Dec 2006
Location:
Posts: 33
Default

OK so you've got the door frame, then the nuts used as spacers, then the speaker, then the longer screws holding it all together, and then on top of all that you've got the door cover paner, and it all fits? That sounds OK with me! I was imagining that the speakers would end up being on the outside of the door panel cover, but maybe not!
__________________
2001 Dodge Ram 1500, with 5.2 liter V8 engine, and 4WD. About 150,000 miles as of 12/30/06. Manual transmission, long bed.
Reply With Quote
  #6
Old 05-26-2010, 07:19 PM
revvinram revvinram is offline
Professional
Garage is empty, add now

Join Date: Jan 2009
Vehicle: 99 Dodge Ram 1500 5.2
Location: Delaware
Posts: 134
Default

I have the spacer and the long screws that came with the new speakers on mine there is no issues with my panel going right back on.
Reply With Quote
  #7
Old 05-26-2010, 09:16 PM
dhvaughan's Avatar
dhvaughan dhvaughan is offline
Hall Of Fame
Garage is empty, add now

Join Date: Jul 2006
Vehicle: 01 1500 4wd
Location: Gainesville, Ga.
Posts: 12,192
Default

i installed rockford p4 6x9 and used a 1/4 inch nut as a spacer. they were 3 inches deep and sit just off the window frame. they have a fairly shallow height, so the door panel just "barely" bulges a little, not much. see my picture thread over in the audio section.
http://dodgeforum.com/forum/audio-vi...-speakers.html

edit. i looked at some pioneer speakers that had less depth, but a lot more height, and they would have bulged out more.
__________________
01 1500 Reg Cab 4wd 5.2 auto 3.55 285/75/16 steps tow hooks sc3815 180 3923 trans cooler filter posilok powertrax (removed) timbren britebox pioneer head rockford amp speaker cobra cb firestick hughes plenum water pump timing chain oil pump rear main hub bearings brakes shocks cracked dash cad bushings seals ujoints trackbar tcase Robert Griffin Trans
Reply With Quote
  #8
Old 05-28-2010, 10:12 PM
althorp althorp is offline
Registered User
Garage is empty, add now

Join Date: Dec 2006
Location:
Posts: 33
Default Thanks for the photos

That series of photos is immensely helpful dhvaughan. Thanks.

By the way, if the back of the speaker touches the window guide rail, will that affect sound quality? I just did a similar installation on another vehicle, and while the speaker as installed did not interfere with the window movement, it probably touches the guide rail, and so I wondered about that.
__________________
2001 Dodge Ram 1500, with 5.2 liter V8 engine, and 4WD. About 150,000 miles as of 12/30/06. Manual transmission, long bed.
Reply With Quote
  #9
Old 05-28-2010, 10:22 PM
dhvaughan's Avatar
dhvaughan dhvaughan is offline
Hall Of Fame
Garage is empty, add now

Join Date: Jul 2006
Vehicle: 01 1500 4wd
Location: Gainesville, Ga.
Posts: 12,192
Default

i don't think having the magnet touch the frame will affect sound, however, it might rattle, so i would try and avoid it. if you can't avoid it, glue in a thin piece of high density foam to prevent rattle.
__________________
01 1500 Reg Cab 4wd 5.2 auto 3.55 285/75/16 steps tow hooks sc3815 180 3923 trans cooler filter posilok powertrax (removed) timbren britebox pioneer head rockford amp speaker cobra cb firestick hughes plenum water pump timing chain oil pump rear main hub bearings brakes shocks cracked dash cad bushings seals ujoints trackbar tcase Robert Griffin Trans
Reply With Quote
  #10
Old 05-28-2010, 11:01 PM
GC99RAM GC99RAM is offline
Professional
Garage is empty, add now

Join Date: Mar 2010
Vehicle: 1999 Dodge Ram Quad Cab 4x4 & 1999 Dodge Durango 2WD 5.9
Location: Minneapolis MN
Posts: 113
Default

This is all news to me...

I installed a set of 5 way Kenwoods without any issues or spacers. I dunno
